EPOXY SPLASH ZONE COATING |
|
| PRODUCT NUMBER | 1085SP |
|
TYPE |
A two-pack and spray-type of high solids corrosion preventive coating based on special epoxy resin. |
|
USES |
Used for steel and concrete structures located at shore exposed and immersed in water, harbor facilities, splash zone. |
| CHARACTERISTICS | 1. Can easy to apply in water with good adhesion. 2. Very good permeability for wet or rusted surface, can inhibit corrosion and rusting speed. 3. Excellent resistance to water and cathodic protection. 4. Hard and tough film with excellent abrasion resistance. 5. Excellent resistance to oils and chemicals. 6. 1500 microns of dry film can be obtained by one coat spray. |
|
FINISH |
Flat |
|
COLOR |
Desired colors |
|
MASS DENSITY |
Above 1.4 Kg/L (mixture, depending on colors) |
|
VISCOSITY |
Above 120 KU (mixture, 25℃) |
|
DRYING TIME |
Set-to-touch 2 hrs. Dry hard 8 hrs. Fully cured 7days (25℃) |
|
OPTIMUM FILM THICKNESS |
Wet 1660 microns Dry 1500 microns |
| VOLUME SOLIDS | Above 90% |
|
THEORETICAL COVERAGE |
0.6 ㎡/L 0.43 ㎡/Kg |
|
OVERCOATING INTERVALS |
Min. 12 hrs. Max. 7 days (20℃) |
|
MIXING RATIO |
Base : hardener = 86.7 : 13.3 (by wt.) |
|
THINNER |
No.1005 Epoxy Thinner (SP-12) (Only for cleaning tools) |
| PRECEDING COATS | No.700 Moisture Cured Polyurethane Maintenance Primer No.1073 Epoxy Clear Cement Primer |
| SUBSEQUENT COATS | Epoxy or Polyurethane system |
| STORAGE SHELF LIFE | Minimum 1 year under normal storage conditions. |
|
APPLICATION METHOD |
Airless spray |
| FOR AIRLESS SPRAY | Tip Size 0.035” ~ 0.045” Air pressure 5~6 Kg/cm2 Pump Ratio 60 : 1 or greater |
|
NOTE |
1. Mix base and hardener according to the mixing ratio and stir thoroughly. 2. All equipment must be cleaned immediately after use. 3. When used inside tanks, sufficient ventilation must be provided. 4. The water if had on the surface of cement or steel substrate must be removed thoroughly. 5. The rise of moisture of cement surface will generate pressure to make adhesion fail. 6. The cement surface adhered moss, dust or grease must be
used high jet water at 3000-4000 psi or with a manual or powered steel brush to
remove clean. |
|
|
|
|
 |
|
|
|
