INORGANIC ZINC RICH PRIMER-IZ-01HS-1011

INORGANIC ZINC RICH PRIMER-IZ-01HS

Specification Data

Type

A two-pack, solvent based inorganic zinc rich rust preventive paint based on ethyl silicate and high purity zinc dust.

Uses

Used for steel structures of power plants, harbor facilities, bridges, water pipelines and storage

tanks to extend the protection of life.

Characteristics

˙High zinc loading.

˙Excellent resistance to oil, mechanical damage and organic solvents.

˙High slip co-efficient, can be used on faying surface.

˙High anti-corrosive performance, can extend the protection of life.

Color

Finish

Gray

Flat

Service Temperature

Untopcoated: Continuous 400℃(750℉);Non-Continuous 427℃(800℉)

VOC values

Solids Content

With recommended Inorganic copolymer topcoat (NO.1569 Min.DFT 2mils)

Continuous 538℃(1000℉),Non-Continuous 649℃(1200℉).

456 g/L ; Use SP-13 thinner to thin up 5% (468 g/L).

By Weight Above 80% (mixture)

Zinc Content in Dry

Film

By Weight Above 85%

Theoretical Coverage

Dry Film Thickness

34 m2/Gal ( 366 ft2/Gal ) 9 m2/L ( 96.9 ft2/L ) 3.62 m2/Kg( 39 ft2/Kg ) ( DFT :3 mils)

3-4 mils (75-100 microns).

Dry film thickness in excess of 5 mils (125 microns) per coat is not recommended

Preceding Coats

Chlorinated Rubber, Epoxy, Vinyl, Silicone or PU system

A mist coat is required to minimize topcoat bubbling except for some topcoats (high-solids epoxy)

Repair

Use organic zinc epoxy paint to repair(YCP EP-03AA)

Performance Data

Test Method

System

Results

CNS 11584 K6854

Test for Inorganic Zinc Rich Primer

1 ct. IZ-01

Solids content : 80.65%

Zinc content in dry film : 86.7%

ISO 4628-6-07

ASTM D610-08

Cyclic Corrosive Test

Blasted Steel

1 ct. IZ-01 (75 microns)

1 ct. 1569 (50 microns)

Chalking rating : 0.5

Rust grade : 10

ISO 4628-6-07

ISO 4624-02

Cyclic Corrosive Test

Blasted Steel

1 ct. IZ-01 (75 microns)

1 ct. EP-999GF (150 microns)

1 ct. UP-450 (60 microns)

Chalking rating : 0.5

Original adhesive strength : 5.2 MPa

Percentage of adhesive strength retention after cyclic corrosive test : 62.9%(3.27 MPa)

Test Method

System

Results

ASTM D5894-96

ASTM D4541-09

Type VCyclic Corrosive Test

Blasted Steel

1 ct. IZ-01 (75 microns)

1 ct. EP-999GF (150 microns)

1 ct. UP-450 (60 microns)

No cracking and peeling in appearance

Original adhesive strength : 8.0 MPa

Percentage of adhesive strength retention after cyclic corrosive test : 69.6%(5.57 MPa)

CNS 11478 K6820 (1995)

Test For Heat Resistance Paint

( 600℃, 48hr )

Blasted Steel

1 ct. IZ-01 (75 microns)

1 ct. 1569 (50 microns)

No blistering, cracking and peeling in appearance

ASTM B117

Salt Spray

Blasted Steel

1 ct. IZ-01 (75 microns)

No blistering, cracking and rusting

after 5000 hrs

ASTM A325

Slip Co-efficient

Blasted Steel

1 ct. IZ-01 (125 microns)

0.47

ASTM F963

Soluble Heavy Metals Test

1 ct. IZ-01

n.d. (Sb、As、Cd、Cr、Pb、Hg、Ba、Se)

Test reports and additional data available upon written request.

Certification

˙CNS 4397 K2088 : Report number 90A0047 ( National Kaohsiung University of Applied Sciences )

˙Norsok M-501-04 : Report number KV-13-04545XA-1 , KV-12-08801XA-1 ( SGS Taiwan Ltd. )

˙CNS 2949 K2050 : Report number KV-14-10793ZA ( SGS Taiwan Ltd. )

Application Instruction

˙Surface preparation

General

Remove dirt, dust, oil and all other contaminants that could interfere with adhesion of the coating.

Surfaces must be clean and dry. Moisture, grease, sludge, dust, corrosive salt must be thoroughly cleaned from substrate.

Surface preparation standards can use SSPC-SP10 or Sa2 1/2 (ISO 8501-1:2007). Blast surface profile 1~3mils (25~75 microns) (Ref. ASTM D4417).

˙Mixing & Thinning

Mixing

Thinning

Mixing Ratio

Pot life

Pour the zinc dust gradually into the base with constant stirring and then pass through 80 mesh filter.

Above 25℃, use HT-type SP-13 thinner to thin up 3~5%. Below 25℃, use LT-type SP-13 thinner to thin up 3~5%

Base : Zinc dust = 23 : 77 ( by weight )

8 hours at 25℃ ( mixture, 77℉)

˙Equipment

Spray Application

Airless

Spray







Brush

Roller

When the relative humidity is lower than 40%, water should be sprayed on after being painted for 30 minutes to promote hardening. The dry film thickness should not exceed 150 um to avoid cracking. This paint do not suitable for repairing or recoating, please use product No.1006 (EP-03AA) for repairing to avoid layer film cracking.

When overcoating, the air in the pores will escape through the next coating and may cause blister. A

mist coat then full coat can reduce this condition:

Spray a thin coat to fill the pores in the IZ-01 film, soon after apply to full specified film thickness to break the blisters.

Caution : In difficult cases it may be necessary to thin the next coat.

Pump ratio 30:1 or greater

Tip size : 0.017’’~ 0.025’’

Output PSI : 2500~3800

For touch-up of areas less than one square foot only. Use medium bristle brush and avoid rebrushing.

Not recommended

˙Environment conditions

Condition

Coating

Surface

Environment

Humidity

Minimum

0℃ (32℉)

0℃ (32℉)

0℃ (32℉)

30%

Maximum

45℃ (113℉)

70℃ (158℉)

45℃ (113℉)

85%

Industry standards are for substrate temperatures to be 3℃(5℉) above the dew point . the product simply requires

the substrate temperature to be above the dew point.

˙Curing Schedule

Surface Temp. &

50% Relative Humidity

Dry to Handle

Dry to Recoat &

Topcoat

0℃ (32℉)

2.5 hours

3 days

5℃ (41℉)

1 hours

2 days

15℃ (59℉)

45 minutes

1 day

25℃ (77℉)

45 minutes

18 hours

35℃ (95℉)

15 minutes

16 hours

˙Cleanup & Safety

Cleanup

Safety

Ventilation

Use No.1012 Inorganic Zinc Rich Thinner (SP-13) to clean. In case of spillage, absorb and dispose of in accordance with local applicable regulations.

Please read and follow all caution statements on this product data sheet and MSDS for this product.

Proper ventilation and protective measures must be provided during application and drying to keep solvent vapor concentrations within safe limits and to protect against toxic or oxygen deficient hazards.

˙Package, Handling & Storage

Shelf Life

Shipping

Weight

Storage

Temperature &

Humidity

Flash Point

Storage

Part A :Minimum 1 years under normal storage conditions

Part B :Minimum 2 years under normal storage conditions

1 Gallon Kit – Part A:2.3 Kg (0.23 Gallon)Zinc Powder:7.7 Kg (0.77 Gallon)

3 Gallon Kit – Part A:6.9 Kg (0.69 Gallon)Zinc Powder:23.1 Kg (2.31Gallon)

5-35℃ (41-95℉)

0-90% Relative Humidity

Part A : 13℃ (55℉)

Zinc Filler : NA

Base and zinc powder storage can not sunlight exposure or temperature exceeds 40℃.
