HIGH SOLIDS EPOXY GLASS FLAKE COATING－EP-988GF

Specification Data

Type

The high solids coating based on epoxy resin with anti-corrosive pigment and mica powder.

Uses

Used for ship, bridges, tanks, pipelines, petrochemical plants and steel structures.

Characteristics

˙Tough and hard film, excellent abrasion resistance.

˙Excellent anti-corrosion and water resistance.

˙Excellent resistance to oils and chemicals.

˙Use green anticorrosion pigment in formula, both excellent inhibitory and hiding performance of corrosive protection for steel.

˙Can be applied to variety types of coating, or be coated a variety types of coating, for the best maintenance coating.

˙When primer use PU700 and topcoat use high weather resistant paint, the anti-corrosion

performance is especially excellent.

Color

Gray, Brown

Finish

Primer

Semi-gloss

Self Priming

VOC values

Volume Solids

130 g/L, use SP-12 thinner to thin up 5% (326 g/L).

Above 90±2%

Theoretical Coverage

34.4 m²/Gal (370.6 ft²/Gal)9.1 m²/L (97.9 ft²/L)6.7 m²/Kg(72.1 ft²/kg)(DFT :4mils)

Dry Film Thickness

Service Temperature

Preceding Coats

Subsequent Coats

4~8 mils(100~200μm) per coat

Continuous : 150℃ (302℉)Non-Continuous : 180℃ (356℉)

IZ-01 / IZ-01HS Inorganic Zinc Rich Primer, No.1006 Epoxy Zinc Rich Primer , No.1020 Epoxy Alloy Primer No.700 One Pack Polyurethane Maintenance Primer, No.1075 Epoxy Aluminum Tripolyphosphate Primer

Epoxy, Polyurethane(UP-450, UP-04), Fluorocarbon(5400F) resin system

Repair

Self Repairing

Test Method

System

Results

ISO 4624(2002)

Pull-Off Adhesion (MPa)

Blasted Steel

1 ct. EP-988 (500 microns)

11 MPa

ASTM D4060-14

Abrasion Resistance (mg)

Blasted Steel

1 ct. EP-988 (500 microns)

26.4 mg

ASTM D2794-93(2010)

Impact Resistance

Blasted Steel

1 ct. EP-988 (500 microns)

There are no cracking and peeling

in appearance

ASTM D2370-98

Tensile Strength (MPa)

Blasted Steel

1 ct. EP-988 (900 microns)

13.8 MPa

Test Method

System

Results

ASTM D2370-98

Elongation at break (%)

Blasted Steel

1 ct. EP-988 (900 microns)

2%

ISO 7253 (2002)

Salt Spray (6000h)

Blasted Steel

1 ct. EP-988 (450 microns)

No film defects and an average of

3.5 mm rust creep at the scribe.

ISO 2812-1 (2007)

Immersion (30% H₂SO₄ ,336h)

Blasted Steel

1 ct. EP-988 (500 microns)

There are no blistering, cracking, flaking

in appearance by visual check.

ISO 2812-1 (2007)

Immersion (30% NaOH ,2160h)

Blasted Steel

1 ct. EP-988 (500 microns)

There are no blistering, cracking, flaking

in appearance by visual check.

ISO 2812-2 (2007)

Immersion (40±1℃ water, 8760h)

Blasted Steel

1 ct. EP-988 (500 microns)

There are no blistering, rusting, cracking, flaking in appearance by visual check.

ISO 6270-1

Water Condensation (8760h)

Blasted Steel

1 ct. EP-988 (500 microns)

There are no blistering, rusting, cracking, flaking in appearance by visual check.

ISO 20340 (2009)

Ageing test (4200h)

Blasted Steel

1 ct. IZ-01HS (60 microns)

1 ct. EP-988 (200 microns)

1 ct. UP-450 (60 microns)

Pass

ISO 20340 (2009)

Ageing test (4200h)

Blasted Steel

1 ct. IZ-01R (60 microns)

1 ct. EP-988 (200 microns)

1 ct. UP-450 (60 microns)

Pass

ASTM F963

Soluble Heavy Metals Test

1 ct. EP-988

n.d. (Sb、As、Cd、Cr、Pb、Hg、Ba、Se)

General

Remove dirt, dust, oil and all other contaminants that could interfere with adhesion of the coating.

Surfaces must be clean and dry. Moisture, grease, sludge, dust, corrosive salt must be thoroughly cleaned from substrate.

Steel

Primed Surfaces

Areas of

Breakdown and

Damage

Surface preparation standards can use SSPC-SP10 or Sa2 1/2 (ISO 8501-1:2007).

EP-988 should always be applied over a recommended anti-corrosive coating scheme. The primer surface should be dry and free from all contamination and EP-988 must be applied within the overcoating intervals specified (consult the relevant product data sheet).

It should be prepared to the specified standard (Sa2 1/2 (ISO 8501-1:2007) or SSPC-SP6, Abrasive Blasting or SSPC-SP11, Power Tool Cleaning) and patch primed prior to the application of EP-988.

Mixing

Thinning

Mixing Ratio

Pot life

Mix base and hardener according to the mixing ratio and stir thoroughly.

Use Epoxy Thinner (SP-12) to thin up 0-5%.

Base : Hardener = 79.3 : 20.7 ( by weight )

4 hours at 25℃ ( mixture, 77℉)

Spray Application

Airless

Spray

Brush

Roller

Avoid applying the paint in rainy weather or the relative humidity exceed 85%, particularly, a wet surface must be thoroughly dried. All equipment must be cleaned immediately after use. To increase or decrease the usage of thinner depending on the temperature of the coated surface, the temperature decreased may have to add more amount of thinner

Pump ratio 45:1 or greater

Tip size : 0.025’’~ 0.029’’

Output PSI : 2800~4000.

Application by brush is applicable. For special condition please consult with product manufacturer.

Application by brush is applicable. For special condition please consult with product manufacturer.

Condition

Coating

Surface

Environment

Humidity

Minimum

10℃ (50℉)

10℃ (50℉)

10℃ (50℉)

30%

Maximum

35℃ (95℉)

55℃ (131℉)

45℃ (113℉)

85%

Surface Temp. &

50% Relative Humidity

Dry to Handle

Dry to Recoat &

Topcoat

10℃ (50℉)

12 hours

24 hours

15℃ (59℉)

8 hours

16 hours

25℃ (77℉)

5 hours

8 hours

35℃ (95℉)

2 hours

4 hours

Cleanup

Safety

Ventilation

Use Epoxy Thinner (SP-12) to clean. In case of spillage, absorb and dispose of in accordance with local applicable regulations.

Please read and follow all caution statements on this product data sheet and MSDS for this product.

Proper ventilation and protective measures must be provided during application and drying to keep solvent vapor concentrations within safe limits and to protect against toxic or oxygen deficient hazards.

Shelf Life

Shipping

Weight

Storage

Temperature &

Humidity

Flash Point

Storage

Part A :Minimum 2 years under normal storage conditions

Part B :Minimum 1 years under normal storage conditions

Part A : 1 Gallon － 4.3kg5 Gallon － 21.5kg

Part B : 1 Gallon － 1.3kg5 Gallon － 6.5kg

5-35℃ (41-95℉)

0-90% Relative Humidity

Above 25℃

Store in cool ventilated place, do not exposed to the sun in outdoor to avoid affecting the quality.
