1061H(EP-999H) HIGH SOLIDS EPOXY COATING

HIGH SOLIDS EPOXY COATING

PRODUCT NUMBER

1061H(EP-999H)

TYPE

A two-pack, multipurpose high solids coating based on special epoxy resin and hardener with chemical resistance pigment and rust conversion agent for dual-use as a topcoat or primer.

USES

Used for the cement products, galvanized steel and the steel structures of bridge, storage tank, pipeline, ship etc.

CHARACTERISTICS

1. The best green paint, low solvent content and low pollution.

2. With special resin and rust conversion agent, the wettability of steel surface, and the permeability of corrosive surface, and the adhesion are particularly outstanding.

3. High solid content, it can be coated in or can be coated with a variety of coatings.

4. Tough and hard film, excellent abrasion resistance, also suitable as a floor coating.

5. Excellent resistance to water and sea water, also suitable for tank lining.

6. Excellent resistance to oils, solvents and chemicals

7. The power or manual tools can be used to remove the rust in the situation that had no sand blasting equipment.

8. If want to keep the bright paint film, the recommendation is to coat one layer of PU finish.

FINISH

Semi-gloss

COLOR

Silver or desired colors

VISCOSITY

100~130 KU (mixture)

MASS DENSITY

Above 1.4 Kg/L (mixture, depending on colors) (Silver : 1.10 Kg/L)

DRYING TIME

Set-to-touch 6 hrs.

Dry hard 20 hrs. Fully dried 7 days (25 ℃)

FILM THICKNESS

Wet 120~300 microns

Dry 100~250 microns

THEORETICAL COVERAGE 30.3 ㎡/Gal 8.0 ㎡/L 5.71 ㎡/Kg. (@100μ)

OVERCOATING INTERVALS

Min. 14 hrs. Max. 7 days(No.1061H/No.745)or 3 months(No.1061H/No.1061H).

MIXING RATIO

Base: Hardener = 50: 50 (by wt.)

VOLUME SOLIDS

83% (mixture) (Silver : 88%)

HEAT RESISTANCE

Continuous 38℃ (wet) 93℃ (dry) intermittent 180℃

POT LIFE

2 hrs. (mixture)

THINNER

No. 1005 Epoxy Thinner (SP-12)

THINNING RATE

0~5% (by wt., cleaning tools excluded)

SUBSEQUENT COATS

PU or YungFlon system

PRECEDING COATS

Steel:No.1011 Inorganic Zinc Rich Primer (IZ-01)

No.1027 Epoxy Zinc Rich Primer, AA (EP-03AA) Cement:No.1073 Epoxy Clear Cement Primer

STORAGE SHELF LIFE

Minimum 1 year under normal storage conditions.

APPLICATION METHOD Airless Spray, Brush, Roller

NOTE

1. Mix base and hardener according to the mixing ratio and stir thoroughly, then keep static about 10 to 20 minutes before use.

2. Adhered moisture, grease, dirt, dust, rust and corrosion salts on substrate must be removed thoroughly.

3. Avoid applying the paint in rainy weather or humidity above 85% RH, particularly a wet surface must be thoroughly dried

4. All equipment must be cleaned immediately after use.

5. When used inside tanks, and sufficient ventilation must be provided.

6. When overcoating interval is exceeded, paint surface must be roughened to ensure adhesion.

7. The paint film exposed to the sun for a long-term does have chalking phenomenon that is without affect the quality of paint film.
