EPOXY TOPCOAT |
||
|
NO |
No.1001/ No.1055/ No.1056(EP-04) |
|
|
TYPE |
A two-pack, multipurpose epoxy finish coating based on Epoxy Resin. |
|
|
USES |
Topcoat for cement products, bridge, steel pipes, steel structure of factories. |
|
|
CHARACTERISTICS |
1. Tough, hard film and high abrasion resistance. 2. Excellent resistance to sea water. 3. Excellent resistance to mechanical damage. 4. Very good resistance to oil and mild chemicals |
|
|
APPLICATION METHOD |
Airless Spray, Brush, Roller. |
|
|
COLOR |
Desired colors |
|
|
FINISH |
Gloss |
|
|
SPECIFIC GRAVITY |
Above 1.1 kg/L, depending on colors (Mixture) |
|
|
VISCOSITY (25℃) |
70 ～ 85 KU (Mixture) |
|
|
DRYING TIME (25℃) |
Set-to-touch Dry hard Fully cured |
2 hrs. 10 hrs. 7 days. |
|
OVERCOATING INTERVALS (25℃) |
Min. Max. |
8 hrs. 5 days. (25℃) or 3 days. (30℃) |
|
OPTIMUM FILM THICKNESS |
Wet Dry |
100 microns 40 microns |
|
VOLUME SOLIDS |
Above 60%(Mixture) |
|
|
THEORETICAL COVERAGE |
10㎡/L 9 ㎡/KG 38㎡/GL |
|
|
THINNER |
SP-12 Epoxy Thinner |
|
|
THINNING RATE |
5 ～ 10 ％(by wt.) |
|
|
PRECEDING COATS |
Epoxy Primer |
|
|
Epoxy M.I.O. |
||
|
STORAGE SHELF LIFE |
Minimum 1 year under normal storage conditions. |
|
|
MIXING RATIO |
Base : Hardener = 92 : 8 (by wt.) |
|
|
POT LIFE |
8 hrs. (Mixture) (25℃) |
|
|
NOTE |
1. Mix base and hardener according to the mixing ratio and stir thoroughly. 2. Remove any soap, dust, rust, grease, old paint surface or any salt-containing chemicals before coating. 3. Avoid applying the paint in rainy weather or humidity above 85% RH, particularly, a wet surface must be thoroughly dried 4. All equipment must be cleaned immediately after use. 5. When used inside tanks, sufficient ventilation must be provided. 6. When overcoating interval is exceeded, paint surface must be roughened to insure adhesion. 7. Chalking would not have anything wrong by sunshine. |
|
|
|
|
|
 |
|
|
|
